Mono Sun-Sub 200W / small system

Mono Sun-Sub 200W Solar Pump System

The Mono Sun-Sub 200W Solar Pump System is a small solar-powered submersible pump package designed for low-flow rural water supply, stock watering, small trough systems, tank filling and off-grid bore pumping.

This system is suited to smaller rural jobs where reliable water transfer is needed without mains power or diesel. It is commonly used on farms, lifestyle blocks and remote properties for pumping water from bores, wells and tanks into storage tanks or trough systems.

The Mono Sun-Sub 200W system is a good option for smaller stock water setups, low daily water demand and short to medium pipe runs where the total head is within the pump’s suitable range.

Common Uses

Small stock watering systems
Small trough lines
Tank filling
Remote rural water supply
Off-grid bore pumping
Lifestyle blocks
Low-flow farm water systems
Small solar bore pump installations

Key Features

Solar-powered submersible pump system
Designed for off-grid water supply
Suitable for bores, wells, tanks and rural water systems
No diesel fuel or mains power required
Good option for smaller stock water and trough systems
Brushless DC submersible motor
Solar motor controller with MPPT power tracking
Variable speed control for flow adjustment
Can be used with float switches or pressure control setups
Suitable for rural and agricultural water transfer

Flow & Head Guide

Approximate average daily output for the Mono Sun-Sub 200W system.

Total Head	Approx. Daily Flow
5m	28 kL/day
10m	24 kL/day
15m	21 kL/day
20m	18 kL/day
25m	16 kL/day
30m	14 kL/day
35m	10 kL/day
40m	9 kL/day
45m	8 kL/day
50m	8 kL/day
55m	7 kL/day
60m	6 kL/day

Best Suited For

The Mono Sun-Sub 200W system is best suited for smaller applications where the required daily water volume is moderate and the total pumping head is not too high.

It is a practical choice for small stock water systems, single trough setups, smaller holding tanks, lifestyle blocks and lower-flow bore pumping jobs.

For deeper bores, long pipe runs, higher elevation, larger tanks or multiple trough systems, a larger Mono Sun-Sub system may be required.

Choosing the Right System

When selecting a Mono Sun-Sub 200W system, consider:

Bore depth
Standing water level
Pumping water level
Total head height
Pipe size
Pipe length
Number of troughs or tanks
Required daily water volume
Bore yield
Solar exposure
Fittings, valves and pressure loss

Important Sizing Note

The 200W Sun-Sub system is a smaller solar pump system. It can be a great fit for low-flow stock water and tank filling jobs, but it must be matched to the site.

Flow rates can reduce significantly with higher head, longer pipe runs, smaller pipe sizes, poor solar exposure or extra fittings and valves.

FAQs

What is the Mono Sun-Sub 200W system used for?

The Mono Sun-Sub 200W system is used for small off-grid water pumping jobs such as stock watering, trough filling, tank filling, small bore pumping and rural water supply.

Is the Mono Sun-Sub 200W suitable for stock water?

Yes. It can be suitable for small stock water systems, single trough setups and lower daily water demand applications, depending on head height, bore yield and pipe distance.

Can the Mono Sun-Sub 200W pump from a bore?

Yes. The Sun-Sub range is designed for submersible bore pumping applications. The correct model should be selected based on bore depth, pumping water level, total head and required daily water volume.

How much water can the Mono Sun-Sub 200W pump?

As a guide, the 200W system can pump approximately 28 kL/day at 5m head, 18 kL/day at 20m head, 9 kL/day at 40m head and 6 kL/day at 60m head under good solar conditions.

Does the Mono Sun-Sub 200W need mains power?

No. The system is solar powered, making it suitable for remote areas where mains power is not available or diesel pumping is not preferred.

Disclaimer

Flow rates shown are manufacturer-published guide figures based on controlled testing and good solar conditions. Actual flow rates may vary depending on sunlight, location, bore depth, water level, pipe size, pipe length, elevation, fittings, valves, bore yield, system design and installation conditions.

Flow rates are provided as a guide only and should not be relied upon as guaranteed performance. For best results, contact The Pump Shed Australia with your bore depth, distance, height lift and required daily water volume so the correct Mono Sun-Sub system can be selected.
